Veloce 4 Place Plane
Gen 2
$25,000 Kit
Over 50 Flying with a 30 Year Proven Track Record
Simple Efficient
All Composite like Cirrus
Affordable Kit Plane
Keeping it Simple, G2 plane does not have any complicated systems to worry about.
Plane was developed to lesson the builders workload and requirements.
Making it easier, quicker and faster to build.
The kit contains all materials required to complete the airframe.
In excess of 100 pre-molded composite parts are the bases to assembly.
Constructed of high temperature epoxy resin pre-impregnated fiberglass and carbon fiber
with either Divinycell foam or honeycomb cores cured under vacuum pressure at 250 degrees (F).
They are strong, light weight, and assemble quickly.
All prefabricated metal parts are pre-welded.
Not included in the kit are: Engine/Mount, Instruments, Avionics, Paints, Interior Upholstery and Battery.
Estimated assembly is about 1200 hours for the average builder from scratch.
Specifications
-
Length Overall 25.5 ft.
-
Wing Span 29 ft.
-
Wing Area 135 sq. ft.
-
Height 7.5 ft.
Cockpit Width
-
Front Seats 44 in.
-
Rear Seats 42 in.
-
Cockpit Height 46 in.
-
Cockpit Length 78 in.
Weights
-
Empty Weight 1200 lbs.
-
Gross Weight 2300 lbs.
-
Useful Load 1100 lbs.
-
Fuel Capacity 52 gal.
Performance
-
Top Speed (sea level) 190+ mph
-
Cruise Speed (sea level) 175 mph
-
Stall Speed 55 mph
-
Range 800+ miles w/reserve
Rate of Climb
-
Average Weight 1300 fpm
-
Gross Weight 1100 fpm
-
Take Off Roll 1000 ft.
-
Over a 50 ft. obstacle 1200 ft.
-
Landing Roll 1300 ft.
-
G Loading Standard Category
-
V-Maneuver Speed 145 mph
-
V-f (max flap speed) 110 mph
-
V-ne (never exceed) 215 mph
Prices
$25,000 - KIT
$75,000 – $100,000 -
Build it on your own (kit $25,000 and about $50-$75k more)
$150,000 - Build Assist with these avionics and panel
(VMS 1000C Engine monitor, Dynon EFIS D-100, Dynon HS34,
TruTrak Digiflight II Autopilot with GPSS and altitude hold,
PS Engineering PMA 8000BT audio panel with marker beacons and Bluetooth,
Garmin 430W, Garmin GTX 335 Transponder, and Garmin GPS Map 696.)
$175,000
- Build Assist with full Garmin suite of avionics, IFR and Aerovolare engine.
Can do different engines for a price difference.
Located in Whiteville, NC
