Veloce ANG Patriot Plane with Diesel Engine 150 HP

Lighter, Faster, & Less fuel – Than Any Other Plane

Full Carbon Fiber Aircraft, only metal is the landing gear, engine mount, hinges and some screws.
Only 838 lbs empty
1,262 lbs useful load
Top and Cruise 160 ktas on 7 gph with optional electric hybrid capable of short flying with just electric engine.
200+ HP for take off with inline optional electric motor
Retractable landing gear (with shock absorption system). Allows to develop higher flight speed and have lower fuel consumption compared to fixed landing gear. Fixed is an option.
Increased flap area. Reduces takeoff and landing speed – 43 knots
Computer airborne warning systems. Excludes possible piloting errors (forbidden takeoff weight, unsafe landing gear, etc.)
Auto Pilot with push button to level and safe glide
Parachute Standard – GRS 6 800-990 SDS parachute rescue system manufactured by Czech company Galaxy GRS s.r.o.
Good noise isolation level. Gives passengers the possibility to have a good time during business flights or vacation flights with near and dear ones

ALL FOR $237,000 USD Total for the First One

Includes Our Build Center Fast Build Assist & 150 HP Diesel Engine

Electric Hybrid Additional

Stats		OTHER STATS
Engine	PurPower Diesel 150 HP	Landing gear track	6.2 ft
Type of fuel	Diesel/Jet A	Wheels size	8 inch
Propeller	3-blade, Constant Speed Carbon Prop	Luggage COMPARTMENT	5.7 ft length / 2.8 ft width 330 Ibs – 2 ppl in / 110 Ibs – 5 ppl in.
nUMBER OF pEOPLE	4 adults – 2/3 children	WING LOADING	18 lbs/sq/ft
Maximum take-off weight	2095 Ibs	Fast cruise speed	160 ktas
Empty weight	838 Ibs	Peak speed	180 ktas
Fuel tank volume	65 gal	Cruise speed 65%	155 ktas
Wing area	116.25 sq/ft	Cruise speed 55%	145 ktas
Wingspan	31.5 ft	Landing speed	43 knots
USEFUL LOAD	1,262 lbs	Climbing rate	1,300 ft/m
Headroom	47 inches	Take off Distance	790 ft
Cabin width	52 inches	Landing Distance	492 ft
lANDING gEAR	Three-strut Hydraulic Retractable	Max height full power	23,622 ft
Vx	75 ktas w. climb rate of 1770 ft/m – 2 people	Vy	81 ktas w. climb rate of 1700 ft/m

Options

Alcohol De-ice in wings (Like TKS) – $30k
Full De-Ice/Prop Heat Wing (not alcohol): $45,000
Prop Heat Only: $2,000 (Included in De-Ice)
AC – $10k
Parachute is Standard on all planes

Engine Options

Diesel /Jet A 150 HP – Included
Aerovolare 160 HP Suzuki 1.5L Turbo – Minus $5k
Rotax 916 – Starting at +$10k
Rotax 915 – same price
Turbo Prop – Starting at $50k+
Mwfly – Italy – Additional $5k
Other – $35k Price Credit

Delivery

9-12 months

Thinking of buying a Sling TSI?

Veloce ANG 160 ktas Top and Cruise

Veloce ANG $237k total includes our build center fast build assist equipped same as Sling TSI

Veloce ANG $180k total for everything needed to build yourself, engine, avionics and all parts Vs. Sling is $350k

Comparison

Company	ANG – Rotax 915iS Turbo Charged FADEC 141 HP	Sling TSI – Rotax 915iS Turbo Charged FADEC 141 HP
Website	www.veloceplanes.com/ang	www.airplanefactory.com/aircraft/sling-tsi
Plane	4 adults – 2/3 children	4 place
Total Price	$237,000 (engine and avionics included)	$163K- $199K – (engine and avionics included)
Hours to build	700 hours	900 hours (2 years to deliver)
Engine	SMA Diesel 150 HP	Rotax 915IS Turbo Charged FADEC 141 HP
Cruise	Cruise (65%) 155 ktas Cruise (55%) 145 ktas	155 ktas @ 9,500 ft on 9 GPH
Range	1400 nm	800 nm
Take Off	790 ft	850 ft
Landing	492 ft	850 ft
Empty weight	838 lbs	1080 lbs
Max weight	2095 Ibs	2095 Ibs
Useful load	1262 lbs	1015 lbs

WEIGHT

Aircraft weights

Plane	ANG Patriot – Rotax	Sling TSI – Rotax
Empty weight	838 lbs	1080 lbs
Maximum weight	2095 lbs	2095 lbs
Fuel capacity	65 gal.	45 gal.
Baggage	1719 lbs	40 lbs
USEFUL LOAD	1262 lbs	1015 lbs

Aircraft measurements

Aircraft	ANG Patriot	Sling TSI
Cabin height
Cabin width	52″	44″
Shoulder room		44″
head ROOM	47″
Tail Width		122 inches
Wing span	31.5 ft	31.5 ft
Length
Height

OPTIONS

Accessory

ANG Patriot

Full De-Ice/Prop Heat: $45,000
Prop Heat Only: $2,000 (Included in De-Ice)
AC – $10k
Parachute is standard on all planes
Delivery Times currently 9-12 months

SLING TSI

IFR Instrumentation standard
Factory quick build assist $100k+ more
Gramin Glass Panel Standard

Compare

Company	Veloce ANG	Veloce 400	Van’s aircraft	Van’s aircraft	Sling	Revolution Aviation	Cirrus	Evolution
Website	www.veloceplanes.com/ang	www.veloceplanes.com/400	www.vansaircraft.com	www.vansaircraft.com	www.airplanefactory.com /aircraft/sling-tsi/	http://www.evolutionaviation.net/	https://cirrusaircraft.com	http://www.evolutionaircraft.com
Plane	ANG – 150 hp	400 – 300 – 350 hp – AV	RV-10 2200 lbs	RV-10 2700 lbs	TSI sling	RAI-6 Foxtrot	Cirrus SR20	Evolution Piston
Price KIT	$117,000	$54,700	$49,710- $63,250
Total Price	$237,000	$237,000	$170K- $200K	$170K- $200K	$163K- $191K	$167K	$494,900	1M
Time to build	700	800-1000	1200-2000	1200-2000	900		0	200
Engine	SMA Diesel 150 HP	300 – 350 hp – AV	235 – 260 HP	236 – 260 HP	Rotax 915iS Turbo Charged FADEC 141 HP	Lycoming IO-540 300	Lycoming IO-390-C3B6 215HP	YTEO-540-iE2 350 hp
Cruise	Cruise (65% @ 8000’ 155 ktas; Cruise (55% @8000’) 145 ktas;	Cruise (65% @ 8000’ 200mph Cruise (55% @8000’) 65% power -203 kts @ 18,000 ft	Cruise (75% @ 8000’ 235HP -194mph; 260HP – 201mph); Cruise (55% @8000’) 235HP- 174 mph; 260 HP – 180mph;	Cruise (75% @ 8000’ 235HP -190mph; 260HP – 197mph); Cruise (55% @8000’) 235HP- 170 mph; 260 HP – 176mph;	155+ ktas	174 KTAS	Max Cruise 155ktas; Cruise @8000ft 145kts;	Max Cruise (max @ 24,000) 230 KTAS; Economy Cruise 215 KTAS
Range	1400 NM	1400 NM	600 NM	1000 NM	800 nm	2,000 nm		1380 NM
Take Off	790 ft	850 ft	360-415	500-583		875 ft	1,685 ft	1450 ft
Landing	492 ft	850 ft	500-525	650		800 ft	Landing Groundroll 853 ft	Min Ldg Distance 1650 ft
Stall speed	45 mph	67 mph	57 mph	63 mph		58 kts	57 kts	61 KTS
Empty weight	838 lbs	1480 lbs	1580 –1630 lbs	1581 –1630 lbs	1,080 lbs	1,900 lbs	2122 lbs	2650 lbs
Max weight	2095	2766	2700	2701	2095	3,500	$nbsp;	4550
Useful load	1262 lbs	1286 lbs	1050 lbs	1051 lbs	1015 lbs	1,600 lbs	1,028lbs	Payload (up to)720 lbs
